by Greg Parrish
This setup uses 4 Hella 4000 Lights, 1 Hella rear work light and has the option to easily add two more lights as side lights. I used the following items:
4 Cruise control on/off switches – (from www.discountrovers.com)
3 Rear fog switches – (from www.discountrovers.com)
1 Ashtray/coin-tray switch holder – (from www.discountrovers.com)
3 Fog switches for above ashtray/coin-tray switch holder – (from www.discountrovers.com)
2 Hella 4000 Euro-beams (center of roof rack) – (from www.4x4connection.com)
2 Hella 4000 Cornering Beams (outside of roof rack) – (from www.4x4connection.com)
1 Hella 90601 Work light (rear of roof rack) – (from www.rallylights.com)
2 IPF J-01 Fog/Driving combo (front bumper) – (from www.britishpacific.com)
5 Radio Shack 30 amp relays – (from www.radioshack.com)
1 Splash proof 16 position fuse box – item 62942 – (from www.rallylights.com)
2 Splash proof 4 position relay boxes - 62943 – (from www.rallylights.com)
2 Terminal bus blocks – 10 position – (from www.westmarine.com)
1 Fuse block – with 100 amp wafer fuse – (from www.bestbuy.com)
12 Guage wiring – (from www.homedepot.com)
Misc. Solder, terminals, heat shrink, scotch electrical tape, etc………… (from various suppliers)
